Electric potential energy - Physics 2 AP Study Notes

Electric Potential Energy (EPE) is the energy stored in a system of charges due to their positions in an electric field. Just as gravitational potential energy exists between masses, EPE exists between charges.

Key Definition: Electric potential energy is the work done by an external force in bringing a charge from infinity to a point in an electric field without acceleration.

Fundamental Equations:

1. For two point charges: U = k(q₁q₂)/r

   • U = electric potential energy (joules, J)
   • k = Coulomb's constant (8.99 × 10⁹ N·m²/C²)
   • q₁, q₂ = charges (coulombs, C)
   • r = separation distance (metres, m)

2. For a charge in a uniform field: U = qEd

   • E = electric field strength (N/C or V/m)
   • d = displacement in field direction (m)

3. Relationship to electric potential (V): U = qV

   • V = electric potential at a point (volts, V)

Critical Concepts:

• EPE is a scalar quantity (has magnitude but no direction)
• EPE can be positive or negative: Like charges (both + or both −) have positive EPE; unlike charges have negative EPE
• Zero reference point: EPE is defined as zero when charges are infinitely separated
• Conservation principle: Total energy (kinetic + potential) remains constant in isolated systems

Memory Aid - SPRE: Sign matters, Potential is scalar, Reference at infinity, Energy conserved

The sign convention is crucial: negative EPE indicates an attractive interaction (energy must be added to separate charges), while positive EPE indicates repulsion (energy released when charges separate).

Gravitational Analogy: Electric potential energy mirrors gravitational potential energy. Lifting a book against gravity stores GPE; similarly, pushing a positive charge toward another positive charge (against electric repulsion) stores EPE. The book naturally falls down; like charges naturally fly apart.

Real-World Application 1: Thunderstorms Clouds develop charge separation—negative charges at the base, positive at the top. As charges accumulate, EPE increases dramatically. When EPE reaches a critical threshold (overcoming air's insulation), lightning discharges occur, converting millions of joules of EPE into kinetic energy, light, and heat. The crackling sound is air molecules accelerated by the released energy.

Real-World Application 2: Photocopiers & Laser Printers These devices exploit EPE principles. A charged drum (negatively charged selenium) attracts oppositely-charged toner particles (positive). The EPE difference ensures toner adheres precisely where needed. When paper (given opposite charge) contacts the drum, even greater EPE attraction transfers toner to paper—a carefully orchestrated energy landscape.

Real-World Application 3: Cathode Ray Tubes (older TVs) Electrons accelerated from cathode to anode lose EPE (moving from low to high potential in their reference frame), converting it to kinetic energy. The electron beam's speed—controlled by potential difference—determines impact energy on the phosphor screen, creating visible light.

Van de Graaff Generator: Charges continuously transported to a metal sphere accumulate, increasing EPE. Touch it, and you become a pathway to ground—the sudden EPE release causes the familiar shock and hair-raising effect (like charges on your hair repel, standing on end).

Key Insight: EPE always drives systems toward lower energy states. Like charges separate (reducing positive EPE); unlike charges attract (making negative EPE more negative).
